Data collectors are a key tool in logistics, warehousing, and trade, enabling quick and precise data capture in the field. The MobiPad P2600K is a data collector model designed for professional use. This device boasts increased durability, designed to withstand particularly demanding conditions. It is IP67 certified, confirming its dust-tightness and resistance to short-term immersion in water. Reliable operation in the field is supported by an integrated, high-energy-density gel-polymer battery. Its robust capacity of 5000 mAh at a nominal voltage of 3.8 V (maximum 4.35 V) ensures exceptionally long operating time without the need for frequent

up…    menu…

Specification

Detailed device specification is available in the: "Technical data".

This ruggedized industrial collector runs on Android, which not only provides access to modern business applications and intuitive smartphone operation, but also guarantees the stability and security essential for a corporate environment. This allows for quick and easy integration with existing IT systems and effective real-time data management.

up…    menu…

The MobiPad P2600K was designed with maximum operational efficiency and user comfort in mind. Its slim and streamlined design ensures ease of use, significantly minimizing operator fatigue during prolonged operation. The device maintains a compact size of 168.3*79.5*16.9mm. At the same time, the durable housing protects the collector from damage. This combination of features ensures continuous operations and reliable data reading even in the most demanding industrial environments.

up…    menu…

The device features a 6.217-inch HD+ TFT (IPS) display with a modern water-drop screen design. The screen is protected by reinforced Corning Gorilla Glass 3 and a special oleophobic coating (AF) that effectively reduces fingerprints. Thanks to advanced G+FF technology, the panel offers precise touch response while also enabling comfortable operation with gloves.

he MobiPad P2600K data collector is designed for efficient operation both inside buildings or vehicles, as well as outdoors. Its specially designed display with optimal brightness ensures readability in sunlight, supporting mobile operations.

DATA COLLECTING

Near Field Communication is a key proximity technology that significantly accelerates and simplifies asset identification and authorization in industrial environments. NFC technology in the MobiPad P2600K collector revolutionizes industrial processes by providing fast and secure wireless data exchange. This functionality is crucial for industry, enabling instant product identification, machine access authorization, and streamlining inventory processes. Its speed and ease of use make work significantly more efficient. Furthermore, the instant exchange of information between the device and external systems eliminates the need for manual data entry, minimizing the risk of human error.

The MobiPad P2600K is designed to eliminate errors and accelerate logistics operations. The collector is equipped with an advanced barcode scanning system, powered by the CM60 module. This reliable scanner guarantees rapid and precise reading of all barcode types – from linear (1D) to matrix (2D). This technology ensures efficient and error-free data capture, even in unfavorable lighting conditions or demanding work environments.

up…    menu…

REsistance

Proper protection class is absolutely crucial for devices operating in harsh environments, and the MobiPad P2600K collector meets this requirement, providing uncompromising protection at the IP67 level. Meeting this rigorous standard means that the device for special tasks is characterized by a completely dust-tight housing (number 6) and a high degree of protection against the effects of brief immersion in water (number 7). This makes the device fully protected against dust, dirt, and water ingress during rain or accidental immersion, making it a reliable solution for industries where resistance to external factors and equipment durability are essential.

Firts digit                 Protection level                Second digit
No special protection		No special protection
Protection from solid objects greater than 50mm in diameter		Protection from dripping water
Protection from object not greater than 12mm in diameter		Protection from vertically dripping water (tilted up to 15°)
Protection from object not greater than 2,5mm in diameter		Protection from sprayed water (tilted up to 60°)
Protection from object not greater than 1mm in diameter		Protection from splashed water
Complete protection against contact, Protection against dust deposit		Protection from water projected from a nozzle
Complete protectionm against contact, protection from infiltration of dust		Protection against heavy seas, or powerful jets of water
		Protection against immersion
		Protection against complete, continuous submersion in water

The MobiPad P2600K is a collector designed for extreme durability and longevity. Its robust and precisely crafted casing guarantees unwavering resistance to accidental, destructive drops. The device remains fully functional and ensures complete security of key data even after being struck from a height of 1.5 meters onto a hard surface. This reliability ensures the collector is always ready for action, becoming an invaluable tool for professionals.

The MobiPad P2600K is a professional data collector designed to operate in all, even the most demanding, thermal and environmental conditions. Thanks to its wide operating range, it can operate continuously in temperatures ranging from -20°C to 55°C. The device is also fully resistant to high humidity, operating without issue in environments with relative humidity ranging from 5% to 95% (non-condensing). In storage mode, it can withstand extreme temperatures ranging from -40°C to 70°C. Additionally, the collector provides electrostatic discharge (ESD) protection of ±8 KV (contact) and ±15 KV (air). These comprehensive safeguards ensure long-term reliability and operational stability of the device in the most extreme industrial applications.

up…    menu…

wireless communication

In data collection, a satellite navigation system is crucial for geolocating collected information and precisely positioning workers in the field. The MobiPad P2600K ensures global reliability thanks to multi-system support, including GPS, BeiDou, Galileo, GLONASS, and A-GPS. This combination guarantees fast and accurate location determination in any workspace.

Bluetooth is a universal short-range wireless communication standard essential in industrial environments for connecting collectors to peripheral devices such as mobile printers and headsets. The latest versions of this technology offer minimal power consumption while increasing range and connection stability, significantly improving fieldwork efficiency.

Stable and fast wireless connectivity is essential for uninterrupted data flow in modern logistics. Dual-band Wi-Fi provides fast and reliable access to the corporate network, crucial for continuous data synchronization and real-time resource management. This functionality allows operators to instantly transmit inventory and order information to, for example, a Warehouse Management System (WMS) and download updates, ensuring operational stability in the warehouse and plant.

up…    menu…

Application

The demands of modern sales require the integration of field-resistant hardware with advanced software features. This collector is essentially an Android-based mobile work center, designed to maximize sales representatives' tasks. It guarantees reliable and intuitive management of extensive customer and product databases, enabling rapid searches for relevant information. Thanks to integrated GSM and dual-band Wi-Fi support, the collector ensures the immediate and secure flow of key documents—such as orders and invoices—directly to company headquarters, speeding up transaction processing.

do góry…    menu…

The MobiPad P2600K is the definition of operational readiness. It's a specialized industrial collector, built to withstand the challenges of the harshest operating environments. Its housing meets the rigorous IP67 protection class, ensuring complete resistance to dust and the effects of brief immersion in water. This uncompromising durability makes the device ideal for applications in construction, logistics, and manufacturing—anywhere where traditional equipment would quickly fail. It's a guarantee of durability you can rely on day after day.

Forget about the compromises that slow down your supply chain. The MobiPad P2600K is more than just hardware; it's a command center in the palm of your hand, delivering efficiency and precise warehouse control. This advanced data collector is designed to significantly improve logistics operations. It enables the quick and precise execution of key tasks such as receiving and issuing goods, price control, order management, and monitoring warehouse status and inventory processes.

up…    menu…

Accessories and available versions

The MobiPad P2600K is a collector that won't disappoint even in the most demanding and challenging operating conditions. The device is available in a wide range of versions, easily tailored to your company's specific needs. To learn the detailed technical specifications of a given hardware configuration, simply click on its number in the table below. If you need to create your own custom version, please contact us – we will be happy to prepare a configuration tailored to your unique requirements.

More photos in full resolution available in the: "Gallery".
